S2VNA and S4VNA SCPI Programming Manual
263
SENS:CORR:COLL:SUBC
SENSe <Ch> :CORRection:COLLect[:ACQuire]:SUBClass <numeric>
SENSe <Ch> :CORRection:COLLect[:ACQuire]:SUBClass?
Description
Selects the subclass number of calibration standard used for
measurement by the subsequent command SENS:CORR:COLL:XXXX. If the
calibration kit contains several calibration standards of the same type,
say SHORTs, this allows select the particular SHORT. The subclasses
must be set in advance by the commands SENS:CORR:COLL:CKIT:ORD:XXXX
or in the user interface “Specify Classes”.
Target
Calibration kit, selected for channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<numeric> the subclass number from 1 to 8
Query Response
<numeric>
Preset Value
1
Equivalent Softkeys
None
SENS:CORR:COLL:METH:ERES
SENSe <Ch> :CORRection:COLLect:METHod:ERESponse <rcvport> , <srcport>
Description
Selects the ports and sets the one path 2–port calibration type for
the calculation of the calibration coefficients on completion of the
calibration executed by the SENS:CORR:COLL:SAVE command.
(no query)
Target
Channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<rcvport> the number of the receiver port from 1 to 2 (or 4)
<srcport> the number of the source port from 1 to 2 (or 4)
Out of Range
f the same port numbers are specified, an error occurs.
Related Commands
SENS:CORR:COLL:SAVE
Equivalent Softkeys
Calibration > Calibrate > One Path 2–Port Cal > Select Port
