S2VNA and S4VNA SCPI Programming Manual
92
CALC:FORM
CALCulate <Ch> [:SELected]:FORMat <char>
CALCulate <Ch> [:SELected]:FORMat?
Description
Sets or reads out the trace format.
(command/query)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<char> Specifies the trace format:
MLOGarithmic : Logarithmic magnitude
PHASe : Phase
GDELay : Group delay time
SLINear : Smith chart format (Lin)
SLOGarithmic : Smith chart format (Log)
SCOMplex : Smith chart format (Real/Imag)
SMITh : Smith chart format (R + jX)
SADMittance : Smith chart format (G + jB)
PLINear : Polar format (Lin)
PLOGarithmic : Polar format (Log)
POLar : Polar format (Real/Imag)
MLINear : Linear magnitude
SWR : Voltage standing wave ratio
REAL : Real part
IMAGinary : Imaginary part
UPHase : Expanded phase
Query Response
{MLOG|PHAS|GDEL|SLIN|SLOG|SCOM|SMIT|SADM|PLIN|PLOG|
POL|MLIN|SWR|REAL|IMAG|UPH}
Preset Value
MLOG
Equivalent Softkeys
Format > { Log Mag | Phase | Group Delay | Lin Mag | SWR | Real | Imag |
Phase > 180 }
Format > Smith > { Log/Phase | Lin/Phase | Real/Imag | R+jX | G+jB }
Format > Polar > { Log/Phase | Ling/Phase | Real/Imag }
