S2VNA and S4VNA SCPI Programming Manual
49
CALC:FSIM:BAL:DMC:BPOR:USER:FIL
CALCulate< Ch >:FSIMulator:BALun:DMCircuit:BPORt< Bpt >:USER:FILename <string>
CALCulate< Ch >:FSIMulator:BALun:DMCircuit:BPORt< Bpt >:USER:FILename?
Description
Specifies a file defining the 2-port network which is used in the
differential matching circuit, for the specified balanced port
number Bpt of the channel Ch. The *.s2p file contains the circuit S–
parameters in Touchstone format.
(command/query)
Target
Balanced Port <Bpt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Bpt>={[1]|2}, 1 or 2 for the Bal-Bal topology, always 1 for the SE-Bal,
SE-SE-Bal and Bal topology
Parameter
<srting>, up to 256 characters
Notes
If the full path of the file is not specified, the \FixtireSim subdirectory of
the application directory will be searched for the file.
Related Commands
CALC:FSIM:BAL:DMC:BPOR:TYPE
Equivalent Softkeys
Analysis > Fixture Simulator > > Diff Matching > Bal Port n > User File
