S2VNA and S4VNA SCPI Programming Manual
66
CALC:FSIM:EMB:TYPE
CALCulate <Ch> :FSIMulator:EMBed:TYPE <char>
CALCulate <Ch> :FSIMulator:EMBed:TYPE?
Description
Selects the Topology for the 4-port network embedding/de-
embedding feature.
(command/query, S4 only)
Target
The channel <Ch>={[1]|2|...16}
Parameter
<char> Specifies Topology:
A : Topology A
B : Topology B
C : Topology C
Query Response
{A|B|C}
Preset Value
A
Equivalent Softkeys
Analysis > Fixture Simulator > De–Embedding S4P > Topology > {A| B| C}
CALC:FSIM:SEND:DEEM:STAT
CALCulate <Ch> :FSIMulator:SENDed:DEEMbed:STATe {OFF|ON|0|1}
CALCulate <Ch> :FSIMulator:SENDed:DEEMbed:STATe?
Description
Turns ON/OFF the 2-port network de–embedding function.
(command/query)
Target
The channel <Ch>={[1]|2|...16}
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
0
Equivalent Softkeys
Analysis > Fixture Simulator > De–Embedding > De–Embedding
