S2VNA and S4VNA SCPI Programming Manual
194
MMEM:LOAD:SNP
MMEMory:LOAD:SNP[:DATA] <string>
Description
Loads the Touchstone file with the specified name to the measured
S–parameters of the active channel. The Touchstone file types 1, 2,
3 or 4 port (file extensions s1p, s2p, s3p or s4p) are supported.
On completion of the command, the channel goes to the hold
state.
(no query)
Target
The active channel set by the command SCPI.DISPlay.WINDow(Ch).ACTivate.
Parameter
<string> File name
Equivalent Softkeys
Save/Recall > Load Data From Touchstone File > To S-parameters…
MMEM:LOAD:SNP:TRAC:MEM
MMEMory:LOAD:SNP:TRACe <Tr> :MEMory <string>
Description
Loads the Touchstone file with the specified name to the memory
trace. The Touchstone file types 1, 2, 3 or 4 port (file extensions
s1p, s2p, s3p or s4p) are supported. The current measured S-
parameter of data trace selects the appropriate S-parameter from
the Touchstone file. After successful load the display of memory
trace is automatically switched on.
(no query)
Target
The specified memory trace <Tr> of active channel,
<Tr>={[1]|2|...16}
Active channel set by the command SCPI.DISPlay.WINDow(Ch).ACTivate.
Parameter
<string> File name
Equivalent Softkeys
Save/Recall > Load Data From Touchstone File > To Active Trace
Memory…
