S2VNA and S4VNA SCPI Programming Manual
62
CALC:FSIM:EMB:NETW:TYPE
CALCulate
<Ch>
:FSIMulator:EMBed:NETWork
<Nk>
:TYPE
<char>
CALCulate
<Ch>
:FSIMulator:EMBed:NETWork
<Nk>
:TYPE?
Description
Selects the processing type of the 4-port network embedding/de-
embedding feature.
(command/query, S4 only)
Target
The channel <Ch>={[1]|2|...16},
The Network <Nk>={[1]|2}
Parameter
<char> Specifies processing type:
NONE : No processing
EMBed : Embedding
DEEMbed : De-Embedding
Query Response
{NONE|EMB|DEEM}
Preset Value
NONE
Equivalent Softkeys
Analysis > Fixture Simulator > De–Embedding S4P > Type (ntwk1), Type
(ntwk2) > {None| Embed| De-Embed}
CALC:FSIM:EMB:STAT
CALCulate
<Ch>
:FSIMulator:EMBed:STATe {OFF|ON|0|1}
CALCulate
<Ch>
:FSIMulator:EMBed:STATe?
Description
Turns ON/OFF the 4-port network embedding/de-embedding
feature (command/query, S4 only).
Target
The channel <Ch>={[1]|2|...16}
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
0
Equivalent Softkeys
Analysis > Fixture Simulator > De–Embedding S4P > De–Embedding S4P
