S2VNA and S4VNA SCPI Programming Manual
244
SENS:CORR:COLL:ECAL:INF?
SENSe:CORRection:COLLect:ECAL:INFormation?
Description
Gets information of the AutoCal Module connected to the Network
Analyzer.
(query only)
Target
AutoCal Module
Query Response
The query returns information in a string with comma separated fields.
Autocal Module Information:
Model Name,
Serial Number,
Current Temperature of AutoCal Module,
Selected Characterization Information:
Characterization Name,
Characterization Date and Time,
Min Frequency,
Max Frequency,
Number of Points,
Characterization Temperature,
PortA Connector,
PortB Connector,
PortA Adapter,
PortB Adapter,
Analyzer,
Location,
Operator.
Equivalent Softkeys
Calibration > AutoCal > Characterization Info…
SENS:CORR:COLL:ECAL:ORI:EXEC
SENSe:CORRection:COLLect:ECAL:ORIentation:EXECute
Description
Executes the Auto-Orientation procedure of the AutoCal Module.
The AutoCal Module must be connected to the ports of Analyzer.
(command)
Target
AutoCal Module
Equivalent Softkeys
Calibration > AutoCal > Orientation > Execute Auto-Orientation
