S2VNA and S4VNA SCPI Programming Manual
138
CALC:MATH:FUNC
CALCulate <Ch> [:SELected]:MATH:FUNCtion <char>
CALCulate <Ch> [:SELected]:MATH:FUNCtion?
Description
Selects the math operation between the data trace and the
memory trace. The math result replaces the data trace. If the
memory trace does not exist, the command is ignored.
(command/query)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<char> Specifies the math operation:
DIVide : Division Data / Mem.
MULTiply : Multiplication Data x Mem.
ADD : Addition Data + Mem.
SUBTract : Subtraction Data – Mem.
NORMal : No math
Query Response
{NORM|SUBT|DIV|ADD|MULT}
Preset Value
NORM
Related Commands
CALC:MATH:MEM
Equivalent Softkeys
Display > Data Math > { Data/Mem | Data*Mem | Data+Mem | Data–Mem |
OFF }
CALC:MATH:MEM
CALCulate <Ch> [:SELected]:MATH:MEMorize
Description
Copies the measurement data to the memory trace. Automatically
turns on the display the memory trace.
(no query)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Equivalent Softkeys
Display > Data–>Memory
