S2VNA and S4VNA SCPI Programming Manual
76
CALC:CONV:FUNC
CALCulate <Ch> [:SELected]:CONVersion:FUNCtion <char>
CALCulate <Ch> [:SELected]:CONVersion:FUNCtion?
Description
Sets or reads out the S–parameter conversion function type.
(command/query)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<char> Specifies parameter:
ZREFlection : Reflection equivalent impedance
ZTRansmit : Transmission equivalent impedance
YREFlection : Reflection equivalent admittance
YTRansmit : Transmission equivalent admittance
INVersion : Inverse S–parameter
ZTSHunt : Shunt equivalent impedance
YTSHunt : Shunt equivalent admittance
CONJugation : S–parameter conjugate
Query Response
{ZREF|ZTR|YREF|YTR|INV|ZTSH|YTSH|CONJ}
Preset Value
ZREF
Equivalent Softkeys
Analysis > Conversion > { Zr | Zt | Yr | Yt | 1/S | Z Trans–Shunt |
Y Trans–Shunt | Conjugation }
