S2VNA and S4VNA SCPI Programming Manual
87
CALC:FILT:TIME:SHAP
CALCulate <Ch> [:SELected]:FILTer[:GATE]:TIME:SHAPe <char>
CALCulate <Ch> [:SELected]:FILTer[:GATE]:TIME:SHAPe?
Description
Sets or reads out the gate shape of the gating function.
(command/query)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<char> Specifies the gate shape:
MAXimum : Maximum shape
WIDE : Wide shape
NORMal : Normal shape
MINimum : Minimum shape
Query Response
{MAX|WIDE|NORM|MIN}
Preset Value
NORM
Equivalent Softkeys
Analysis > Gating > Shape > { Maximum | Wide | Normal | Minimum }
