S2VNA and S4VNA SCPI Programming Manual
83
CALC:DATA:SMEM
CALCulate
<Ch>
[:SELected]:DATA:SMEMory
<numeric list>
CALCulate
<Ch>
[:SELected]:DATA:SMEMory?
CALC:TRAC:DATA:SMEM
CALCulate
<Ch>
:TRACe
<Tr>
:DATA:SMEMory
<numeric list>
CALCulate
<Ch>
:TRACe
<Tr>
:DATA:SMEMory?
Description
Reads out or writes the corrected memory array.
The corrected memory array is the data, whose processing is
completed excluding the formatting as the last step. Such data
represent S–parameter complex values.
The array size is 2N, where N is the number of measurement
points.
For the n–th point, where n from 1 to N:
<numeric 2n–1> the real part of corrected measurement memory;
<numeric 2n> the imaginary part of corrected measurement
memory.
(Command/Query)
Target
CALCulate<Ch>[:SELected]:DATA:SMEMory - the active trace of channel,
CALCulate<Ch>:TRACe<Tr>:DATA:SMEMory - the trace <Tr> of channel,
<Ch>={[1]|2|...16}
<Tr>={[1]|2|...16}
Query Response
<numeric 1>, <numeric 2>, …<numeric 2N>
Related Commands
CALC:MATH:MEM
Equivalent Softkeys
None
