S2VNA and S4VNA SCPI Programming Manual
54
CALC:FSIM:BAL:PAR:BBAL
CALCulate
<Ch>
:FSIMulator:BALun:PARameter
<Tr>
:BBALanced[:DEFine]
<char>
CALCulate
<Ch>
:FSIMulator:BALun:PARameter
<Tr>
:BBALanced[:DEFine]?
Description
Selects the measurement parameter of the fixture simulation
function when the device type is BBALanced.
(command/query)
Target
Trace <Tr> of channel <Ch>,
<Tr>={[1]|2|...16}
<Ch>={[1]|2|...16}
Parameter
<char> Specifies the measurement parameter:
SDD11
SDD21
SDD12
SDD22
SCD11
SCD21
SCD12
SCD22
SDC11
SDC21
SDC12
SDC22
SCC11
SCC21
SCC12
SCC22
IMB1 : Imbalance1
IMB2 : Imbalance1
CMRR : Sdd21/Scc21
Query Response
{SDD11|SDD21|SDD12|SDD22|SCD11|SCD21|SCD12|SCD22|SDC11|SDC21|
SDC12|SDC22|SCC11|SCC21|SCC12|SCC22|IMB1|IMB2|CMRR}
Preset Value
SDD11
Related Commands
CALC:FSIM:BAL:DEV
Equivalent Softkeys
Analysis > Fixture Simulator > Measurement > {Sdd11|… CMRR }
