S2VNA and S4VNA SCPI Programming Manual

338

SENS:SEGM:DATA

SENSe

<Ch>

:SEGMent:DATA

SENSe

<Ch>

:SEGMent:DATA?

Description

Sets or reads out the array of the segment sweep table.

The array has the following format:

{ <Buf>, <Flag1>, <Flag2>, <Flag3>, <Flag4>, <Flag5>, <N>,

<Start 1>, <Stop 1>, <NOP 1> [,<IFBW 1>] [,<Pow 1>] [,<Del 1>] [,<Time 1>],

<Start 2>, <Stop 2>, <NOP 2> [,<IFBW 2>] [,<Pow 2>] [,<Del 2>] [,<Time 2>],

…

<StartN>, <StopN>, <NOP N> [,<IFBW N>] [,<Pow N>] [,<Del N>] [,<TimeN>] }

<Buf> : Always 5,

<Flag1> : Stimulus start setting (0 – start/stop, 1 – center/span),

<Flag2> : Setting of the <IFBW> field (0 – disabled, 1 – enabled),

<Flag3> : Setting of the <Pow> field (0 – disabled, 1 – enabled),

<Flag4> : Setting of the <Del> field (0 – disabled, 1 – enabled),

<Flag5> : Setting of the <Time> field (0 – disabled, 1 – enabled),

<N> : Number of segments,

<Start n> : Start value of the n–th segment,

<Stop n> : Stop value of the n–th segment,

<NOP n> : Number of points of the n–th segment,

<IFBW n> : IF bandwidth of the n–th segment (if enabled),

<Pow n> : Power of the n–th segment (if enabled),

<Del n> : Measurement delay of the n–th segment (if enabled),

<Time n> : Reserved for future use (if enabled)

(command/query)

Target

Channel <Ch>,

<Ch>={[1]|2|...16}

Query Response

Where,

N – the number of the segments,

M – depends on the values of the flags:

M = 3 + <Flag2> + <Flag3> + <Flag4> + <Flag5>

Equivalent Softkeys

Stimulus / Segment Table
