S2VNA and S4VNA SCPI Programming Manual
177
DISP:WIND:TRAC:STAT
DISPlay:WINDow <Ch> :TRACe <Tr> :STATe {OFF|ON|0|1}
DISPlay:WINDow <Ch> :TRACe <Tr> :STATe?
Description
Turns ON/OFF the data trace display.
(command/query)
Target
Trace <Tr> of channel <Ch>,
<Tr>={[1]|2|...16}
<Ch>={[1]|2|...16}
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
1
Equivalent Softkeys
Display > Display > Data | Data & Memory (ON)
Display > Display > { Memory | OFF } (OFF)
DISP:WIND:TRAC:Y:AUTO
DISPlay:WINDow <Ch> :TRACe <Tr> :Y[:SCALe]:AUTO
Description
Executes the auto scale function for the trace.
(no query)
Target
Trace <Tr> of channel <Ch>,
<Tr>={[1]|2|...16}
<Ch>={[1]|2|...16}
Equivalent Softkeys
Scale > Auto Scale
