S2VNA and S4VNA SCPI Programming Manual
251
SENS:CORR:COLL:DATA:LOAD
SENSe <Ch> :CORRection:COLLect:DATA:LOAD <port> , <numeric list>
SENSe <Ch> :CORRection:COLLect:DATA:LOAD? <port>
Description
Writes or reads out the array of the load calibration standard
measurement for the port <port>.
The array size is 2N, where N is the number of measurement
points.
For the n–th point, where n from 1 to N:
<numeric 2n–1> real part of the measurement
<numeric 2n> imaginary part of the measurement
(command/query)
Target
Channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<port> the number of the port from 1 to 2 (or 4)
<numeric list> the data array of the load standard measurement
Query Response
<numeric 1>, <numeric 2>, …<numeric 2N>
Related Commands
SENS:CORR:COLL:LOAD
Equivalent Softkeys
None
