S2VNA and S4VNA SCPI Programming Manual
145
CALC:RLIM:DISP:LINE
CALCulate <Ch> [:SELected]:RLIMit:DISPlay:LINE {OFF|ON|0|1}
CALCulate <Ch> [:SELected]:RLIMit:DISPlay:LINE?
Description
Turns ON/OFF the ripple limit line display.
(command/query)
Target
Active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
0
Equivalent Softkeys
Analysis > Ripple Limit > Ripple Limit
CALC:RLIM:DISP:SEL
CALCulate <Ch> [:SELected]:RLIMit:DISPlay:SELect <numeric>
CALCulate <Ch> [:SELected]:RLIMit:DISPlay:SELect?
Description
Sets or reads out the number of the ripple limit test band selected
for the ripple value display.
(command/query)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<numeric>, range from 1 to 12
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
1
Equivalent Softkeys
Analysis > Ripple Limit > Ripple Value Band
