S2VNA and S4VNA SCPI Programming Manual
179
DISP:WIND:TRAC:Y:RLEV
DISPlay:WINDow <Ch> :TRACe <Tr> :Y[:SCALe]:RLEVel <numeric>
DISPlay:WINDow <Ch> :TRACe <Tr> :Y[:SCALe]:RLEVel?
Description
Sets the value of the reference line (response value on the
reference line). For the rectangular format only.
(command/query)
Target
Trace <Tr> of channel <Ch>,
<Tr>={[1]|2|...16}
<Ch>={[1]|2|...16}
Parameter
<numeric> the reference value from 10E–18 to 1E18
Unit
{ dB | ° | s }
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
0 (except for SWR: 1)
Equivalent Softkeys
Scale > Ref Value
