S2VNA and S4VNA SCPI Programming Manual
48
CALC:FSIM:BAL:DMC:BPOR:TYPE
CALCulate< Ch >:FSIMulator:BALun:DMCircuit:BPORt< Bpt >:TYPE <char>
CALCulate< Ch >:FSIMulator:BALun:DMCircuit:BPORt< Bpt >:TYPE?
Description
Selects the type of the differential matching circuit for the
specified balanced port number Bpt of the channel Ch.
(command/query)
Target
Balanced Port <Bpt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Bpt>={[1]|2}, 1 or 2 for the Bal-Bal topology, always 1 for the SE-Bal,
SE-SE-Bal and Bal topology
Parameter
<char> Specifies the differential matching circuit:
NONE : No-circuit
PLPC : Shunt L – Shunt C
USER : User defined circuit by touchstone file
Query Response
{NONE|PLPC|USER}
Preset Value
NONE
Related Commands
CALC:FSIM:BAL:DEV
Equivalent Softkeys
Analysis > Fixture Simulator > > Diff Matching > Bal Port n > {None |
Shunt L - Shunt C | User }
