S2VNA and S4VNA SCPI Programming Manual
243
SENS:CORR:COLL:CKIT:STAN:Z0
SENSe:CORRection:COLLect:CKIT:STAN <Std> :Z0 <numeric>
SENSe:CORRection:COLLect:CKIT:STAN <Std> :Z0?
Description
Sets or reads out the offset Z0 value for the calibration standard.
(command/query)
Target
Standard <Std> of the selected calibration kit,
<Std>={[1]|2|...N}, where N – the number of the standards in
the calibration kit
Parameter
<numeric> the offset Z0 value from –1E18 to 1E18
Unit
Ω (Ohm)
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
50 or 75, depending on the selected calibration kit
Equivalent Softkeys
Calibration > Cal Kit > Define STDs > Offset Z0
SENS:CORR:COLL:CLE
SENSe <Ch> :CORRection:COLLect:CLEar
Description
Clears the measurement data of the calibration standards.
(no query)
Target
Channel <Ch>,
<Ch>={[1]|2|...16}
Equivalent Softkeys
Calibration > Calibrate >
Response (Open) |
Response (Short) |
Response (Thru) |
One Path 2–Port Cal |
Full 1–Port Cal |
Full 2–Port Cal > Cancel > OK
