S2VNA and S4VNA SCPI Programming Manual
291
SENS:CORR:EXT:PORT:LDC
SENSe <Ch> :CORRection:EXTension:PORT <Pt> :LDC <numeric>
SENSe <Ch> :CORRection:EXTension:PORT <Pt> :LDC?
Description
Sets or reads out the loss value at DC for the port extension
function.
(command/query)
Target
Port <Pt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Pt>={[1]|2} for S2VNA or {[1]|2|3|4} for S4VNA
Parameter
<numeric> the loss value from –200 to 200
Unit
dB (decibel)
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
0
Equivalent Softkeys
Calibration > Port Extensions > Loss > Loss at DC
