S2VNA and S4VNA SCPI Programming Manual
402
TRIG:OUTP:FUNC
TRIGger:OUTPut:FUNCtion <char>
TRIGger:OUTPut:FUNCtion?
Description
Selects the trigger output function. The trigger output outputs
various waveforms depending on the setting of the Output Trigger
Function (see the operating manual).
(command/query)
Parameter
<char> Choose from:
BSET : Before frequency setup pulse
BSAM : Before sampling pulse
ASAM : After sampling pulse
RTRG : Ready for trigger signal
ESWP : End of sweep pulse
MEAS : Measurement sweep signal
Query Response
{BSET|BSAM|ASAM|RTGR|ESWP|MEAS}
Preset Value
RTRG
Related Commands
TRIG:OUTP:STAT
Equivalent Softkeys
Stimulus > Trigger > Trigger Output > Function > { Before setup | Before
sampling | After sampling | Ready for trigger | Sweep End | Measurement
}
