Copper Mountain Technologies S2 Series User Manual

S2VNA and S4VNA SCPI Programming Manual
182
DISP:WIND:Y:DIV
DISPlay:WINDow <Ch> :Y[:SCALe]:DIVisions <numeric>
DISPlay:WINDow <Ch> :Y[:SCALe]:DIVisions?
Description
Sets the number of the vertical scale divisions. For the rectangular
format only.
(command/query)
Target
Channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<numeric> the number of the vertical scale divisions from 4 to 30
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
10
Resolution
2
Equivalent Softkeys
Scale > Divisions
