S2VNA and S4VNA SCPI Programming Manual
256
SENS:CORR:COLL:ISOL
SENSe
<Ch>
:CORRection:COLLect[:ACQuire]:ISOLation
<rcvport>
,
<srcport>
Description
Measures the isolation calibration data between the receiver port
<rcvport> and the source port <srcport>.
(no query)
Target
Channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<rcvport> the number of the receiver port from 1 to 2 (or 4)
<srcport> the number of the source port from 1 to 2 (or 4)
Out of Range
If the same port numbers are specified, an error occurs.
Notes
The command starts the measurement immediately if the trigger source
for calibration set to the "Internal" by the command
SENS:CORR:TRIG:FREE, otherwise waits for the trigger signal. The
command blocks the execution of the subsequent commands until the
completion of the measurement.
Equivalent Softkeys
Calibration > Calibrate > Response (Thru) > Isolation (Optional)
Calibration > Calibrate > One Path 2–Port Cal > Isolation (Optional)
Calibration > Calibrate > Full 2–Port Cal > Isolation (Optional)
