S2VNA and S4VNA SCPI Programming Manual
44
CALC:FSIM:BAL:DMC:BPOR:PAR:C
CALCulate< Ch >:FSIMulator:BALun:DMCircuit:BPORt< Bpt >:PARameters:C <numeric>
CALCulate< Ch >:FSIMulator:BALun:DMCircuit:BPORt< Bpt >:PARameters:C?
Description
Sets or reads out the capacitance value of the C element of the
differential matching circuit.
(command/query)
Target
Balanced Port <Bpt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Bpt>={[1]|2}, 1 or 2 for the Bal-Bal topology, always 1 for the SE-Bal,
SE-SE-Bal and Bal topology.
Parameter
<numeric> the capacitance value of the C element of the differential
matching circuit from 1e–18 to 1e18.
Unit
F (Farad)
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
0
Equivalent Softkeys
Analysis > Fixture Simulator > Diff Matching > Bal Port n > C
