S2VNA and S4VNA SCPI Programming Manual
63
CALC:FSIM:EMB:TOP:A:PORT
CALCulate <Ch> :FSIMulator:EMBed:TOPology:A:PORTs <port1> , <port2>
CALCulate <Ch> :FSIMulator:EMBed:TOPology:A:PORTs?
Description
Sets or reads out the test port assignment when the Topology is
set to A, for the 4-port network embedding/de-embedding feature.
(command/query)
Target
The channel <Ch>={[1]|2|...16}
Parameters
<port1> First port number
<port2> Second port number
Query Response
<port1>, <port2>
Preset Value
1,2
Related Commands
CALC:FSIM:EMB:TYPE
Equivalent Softkeys
Analysis > Fixture Simulator > De–Embedding S4P > Ports
