S2VNA and S4VNA SCPI Programming Manual
180
DISP:WIND:TRAC:Y:RPOS
DISPlay:WINDow <Ch> :TRACe <Tr> :Y[:SCALe]:RPOSition <numeric>
DISPlay:WINDow <Ch> :TRACe <Tr> :Y[:SCALe]:RPOSition?
Description
Sets the position of the reference line. For the rectangular format
only.
(command/query)
Target
Trace <Tr> of channel <Ch>,
<Tr>={[1]|2|...16}
<Ch>={[1]|2|...16}
Parameter
<numeric> the reference line position from 0 to the number of the scale
divisions (set by the DISP:WIND:Y:DIV command, 10 by default)
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
5 (except for SWR: 0)
Equivalent Softkeys
Scale > Ref Position
