S2VNA and S4VNA SCPI Programming Manual
67
CALC:FSIM:SEND:DEEM:PORT:STAT
CALCulate <Ch> :FSIMulator:SENDed:DEEMbed:PORT <Pt> :STATe {OFF|ON|0|1}
CALCulate <Ch> :FSIMulator:SENDed:DEEMbed:PORT <Pt> :STATe?
Description
Turns ON/OFF the 2-port network de–embedding function for
specified port.
(command/query)
Target
Port <Pt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Pt>={[1]|2} for S2VNA or {[1]|2|3|4} for S4VNA
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
0
Equivalent Softkeys
Analysis > Fixture Simulator > De–Embedding > Port n
CALC:FSIM:SEND:DEEM:PORT:USER:FIL
CALCulate <Ch> :FSIMulator:SENDed:DEEMbed:PORT <Pt> :USER:FILename <string>
CALCulate <Ch> :FSIMulator:SENDed:DEEMbed:PORT <Pt> :USER:FILename?
Description
Sets or reads out the name of *.s2p file of the de–embedded circuit
of the 2-port network de–embedding function. The file contains
the circuit S–parameters in Touchstone format.
(command/query)
Target
Port <Pt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Pt>={[1]|2} for S2VNA or {[1]|2|3|4} for S4VNA
Parameter
<srting>, up to 256 characters
Notes
If the full path of the file is not specified, the \FixtireSim subdirectory of
the application directory will be searched for the file.
Equivalent Softkeys
Analysis > Fixture Simulator > De–Embedding > S–parameters File
