Copper Mountain Technologies S2 Series User Manual

S2VNA and S4VNA SCPI Programming Manual
46
CALC:FSIM:BAL:DMC:BPOR:PAR:L
CALCulate< Ch >:FSIMulator:BALun:DMCircuit:BPORt< Bpt >:PARameters:L <numeric>
CALCulate< Ch >:FSIMulator:BALun:DMCircuit:BPORt< Bpt >:PARameters:L?
Description
Sets or reads out the inductance value of the L element of the
differential matching circuit.
(command/query)
Target
Balanced Port <Bpt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Bpt>={[1]|2}, 1 or 2 for the Bal-Bal topology, always 1 for the SE-Bal,
SE-SE-Bal and Bal topology.
Parameter
<numeric> the inducitance value of the L element of the differential
matching circuit from 1e–18 to 1e18.
Unit
S (Henry)
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
0
Note
If both elements L and R are equal to zero, then L and R elements are
omited in the sheme. If any element L or R is not zero, then zero value of
the rest element means short circuit.
Equivalent Softkeys
Analysis > Fixture Simulator > Diff Matching > Bal Port n > L
