S2VNA and S4VNA SCPI Programming Manual
403
TRIG:OUTP:POL
TRIGger:OUTPut:POLarity <char>
TRIGger:OUTPut:POLarity?
Description
Sets or reads out the polarity of the trigger output.
(command/query)
Parameter
<char> Choose from:
POSitive : Positive edge
NEGative : Negative edge
Query Response
{POS|NEG}
Preset Value
NEG
Related Commands
TRIG:OUTP:FUNC
Equivalent Softkeys
Stimulus > Trigger > Trigger Output > Polarity > { Negative edge |
Positive edge }
TRIG:OUTP:STAT
TRIGger:OUTPut:STATe {OFF|ON|0|1}
TRIGger:OUTPut:STATe?
Description
Turns ON/OFF the trigger output.
(command/query)
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
0
Related Commands
TRIG:OUTP:FUNC
Equivalent Softkeys
Stimulus > Trigger > Trigger Output > Trigger Output { ON | OFF }
