S2VNA and S4VNA SCPI Programming Manual
20
This section describes in detail how to configure the remote control of the
multiple analyzer programs executed simultaneously on a single computer
(provided several USB analyzer hardware units connected to the single computer).
 It is recommended that you create a separate folder for each analyzer with
the software. This allows you to save individual settings for each analyzer.
 It is recommended that each copy of the software be linked to a specific
hardware unit by its serial number or model (see at the end of this section).
 Assign a unique TCP/IP port number for each copy of the software for the
HiSLIP or Socket protocol used. For example, if HiSLIP is used, assign port
4880 to the first analyzer, 4881 to the second, and so on. When assigning a
port number, the user must ensure that the port number is not used by
other programs.
 Use the analyzer's address in the user program with the mandatory
indication of the TCP/IP port number assigned to the analyzer, as in the
examples given.
Examples of the VISA address for the HiSLIP and Socket protocols with the
indication of the TCP/IP port:
HiSLIP
TCPIP0::192.168.0.1::hislip0,4880::INSTR
TCPIP0::192.168.0.1::hislip0,4881::INSTR
Socket
TCPIP0::192.168.0.1::5025::SOCKET
TCPIP0::192.168.0.1::5026::SOCKET
Examples of the TCP/IP address of the analyzer's Socket server with the indication
of the port:
Socket
192.168.0.1:5025
192.168.0.1:5026
To link the analyzer program to the analyzer model,
press the softkeys:
System > Misc Setup > Analyzer Model
To link the analyzer program to the analyzer serial
number, press the softkeys:
System > Misc Setup > Analyzer Serial N
2.7 Differences in Use of HiSLIP and Socket Protocols
