S2VNA and S4VNA SCPI Programming Manual
297
SENS:CORR:OFFS:COLL:METH:SMIX2
SENSe <Ch> :CORRection:OFFSet:COLLect:METHod:SMIX2 <numeric1> , <numeric2>
Description
Selects the ports and sets the scalar mixer calibration type when the
frequency offset feature is on for the calculation of the calibration
coefficients on completion of the calibration executed by the
SENS:CORR:OFFS:COLL:SAVE command.
(no query)
Target
Channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<numeric1> first port;
<numeric2> second port.
Out of Range
If the same port numbers are specified, an error occurs.
Equivalent Softkeys
Calibration > Mixer/Converter Calibration > Scalar Mixer Calibration
SENS:CORR:OFFS:COLL:OPEN
SENSe <Ch> :CORRection:OFFSet:COLLect[:ACQuire]:OPEN <numeric1> , <numeric2>
Description
Measures the calibration data of the open standard of the specified
port when the frequency offset feature is on for scalar mixer
calibration.
(no query)
Target
Channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<numeric1> Measurement port number
<numeric2> Frequency port number.
Notes
The command starts the measurement immediately if the trigger source
for calibration set to the "Internal" by the command
SENS:CORR:TRIG:FREE, otherwise waits for the trigger signal. The
command blocks the execution of the subsequent commands until the
completion of the measurement.
Equivalent Softkeys
Calibration > Mixer/Converter Calibration > Scalar Mixer Calibration >
Reflection Port n > Port n @Freq m Open
