S2VNA and S4VNA SCPI Programming Manual
209
SENS:CORR:COEF
SENSe <Ch> :CORRection:COEFficient[:DATA] <char> , <rcvport> , <srcport> , <numeric list>
SENSe <Ch> :CORRection:COEFficient[:DATA]? <char> , <rcvport> , <srcport>
Description
Writes or reads out the calibration coefficient data array.
The array size is 2N, where N is the number of measurement
points. For the n–th point, where n from 1 to N:
<numeric 2n–1> real part of the calibration coefficients
<numeric 2n> imaginary part of the calibration coefficients
(command/query)
Target
Channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<char> Specifies the Error term:
ER : Reflection tracking
ED : Directivity
ES : Source match
ET : Transmission tracking
EX : Isolation
EL : Load match
<rcvport> the number of the receiver port from 1 to 2 (or 4)
<srcport> the number of the source port from 1 to 2 (or 4)
<numeric list> the calibration coefficient array
When ES, ER, or ED is used, the numbers of the ports <rcvport> and
<srcport> must be the same. When EL, ET, or EX is used, the numbers
of the ports <rcvport> and <srcport> must be different.
Query Response
<numeric 1>, <numeric 2>, …<numeric 2N>
Notes
The written calibration coefficients become effective only after the
SENS:CORR:COEF:SAVE command is executed.
Related Commands
SENS:CORR:COEF:SAVE
Equivalent Softkeys
None
