S2VNA and S4VNA SCPI Programming Manual
68
CALC:FSIM:SEND:PMC:STAT
CALCulate <Ch> :FSIMulator:SENDed:PMCircuit:STATe {OFF|ON|0|1}
CALCulate <Ch> :FSIMulator:SENDed:PMCircuit:STATe?
Description
Turns ON/OFF the 2-port network embedding function.
(command/query)
Target
The channel <Ch>={[1]|2|...16}
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
0
Equivalent Softkeys
Analysis > Fixture Simulator > Embedding > Embedding
CALC:FSIM:SEND:PMC:PORT:STAT
CALCulate <Ch> :FSIMulator:SENDed:PMCircuit:PORT <Pt> :STATe {OFF|ON|0|1}
CALCulate <Ch> :FSIMulator:SENDed:PMCircuit:PORT <Pt> :STATe?
Description
Turns ON/OFF the 2-port network embedding function for each
port.
(command/query)
Target
Port <Pt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Pt>={[1]|2} for S2VNA or {[1]|2|3|4} for S4VNA
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
0
Equivalent Softkeys
Analysis > Fixture Simulator > Embedding > Port n
