S2VNA and S4VNA SCPI Programming Manual
357
SOUR:POW:PORT:CORR:COLL:TABL:LOSS:DATA
SOURce <Ch> :POWer:PORT <Pt> :CORRection:COLLect:TABLe:LOSS:DATA <numeric
list>
SOURce <Ch> :POWer:PORT <Pt> :CORRection:COLLect:TABLe:LOSS:DATA?
Description
Sets/gets the loss compensation table used when the power
calibration is executed by the SOUR:POW:PORT:CORR:COLL command.
(command/query)
Parameter
The array size is 1+2N, where N is the number of measurement
points.
For the n–th point, where n from 1 to N:
<numeric 1> the number of the table rows N integer from 0 to
10001;
<numeric 2n> the frequency of the n–th row of the table;
<numeric 2n+1> the loss compensation value of the n–th row of
the table from –100 to +100 dB;
Target
Port <Pt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Pt>={[1]|2} for S2VNA or {[1]|2|3|4} for S4VNA
Query Response
<numeric 1>, <numeric 2>, …<numeric 2N+1>
Notes
If the array size is not 1 + 2N, where N is equal to <numeric 1>, an error
occurs. If the <numeric 2n> and <numeric 2n+1> values are out of
the allowable range, the value of the limit, which is closer to the
specified value will be set.
Related Commands
SOUR:POW:PORT:CORR:COLL
Equivalent Softkeys
Calibration > Power Calibration > Loss Compen
