S2VNA and S4VNA SCPI Programming Manual
262
SENS:CORR:COLL:TRLT
SENSe <Ch> :CORRection:COLLect[:ACQuire]:TRLThru <port1> , <port2>
Description
Measures the calibration data of the TRL thru standard between
the <port1> and the <port2>.
(no query)
Target
Channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<port1> the number of the port from 1 to 2 (or 4)
<port2> the number of the port from 1 to 2 (or 4)
Out of Range
If the same port numbers are specified, an error occurs.
Notes
The command starts the measurement immediately if the trigger source
for calibration set to the "Internal" by the command
SENS:CORR:TRIG:FREE, otherwise waits for the trigger signal. The
command blocks the execution of the subsequent commands until the
completion of the measurement.
Equivalent Softkeys
Calibration > Calibrate > n–Port TRL Cal > Thru/Line
SENS:CORR:COLL:TRLR
SENSe <Ch> :CORRection:COLLect[:ACQuire]:TRLReflect <port>
Description
Measures the calibration data of the TRL reflect standard for the
specified port.
(no query)
Target
Channel <Ch>,
<Ch>={[1]|2|...16}
Parameter
<port> the number of the port from 1 to 2 (or 4)
Notes
The command starts the measurement immediately if the trigger source
for calibration set to the "Internal" by the command
SENS:CORR:TRIG:FREE, otherwise waits for the trigger signal. The
command blocks the execution of the subsequent commands until the
completion of the measurement.
Equivalent Softkeys
Calibration > Calibrate > n–Port TRL Cal > Reflect
