Copper Mountain Technologies S2 Series User Manual

S2VNA and S4VNA SCPI Programming Manual
57
CALC:FSIM:BAL:PAR:STAT
CALCulate <Ch> :FSIMulator:BALun:PARameter <Tr> :STATe {OFF|ON|0|1}
CALCulate <Ch> :FSIMulator:BALun:PARameter <Tr> :STATe?
Description
Turns ON/OFF the BalUn function for the specified trace.
(command/query)
Target
Trace <Tr> of channel <Ch>,
<Tr>={[1]|2|...16}
<Ch>={[1]|2|...16}
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
0
Equivalent Softkeys
Analysis > Fixture Simulator > BalUn
CALC:FSIM:BAL:TOP:BAL
CALCulate <Ch> :FSIMulator:BALun:TOPology:BALanced[:PPORts] <port1> , <port2>
CALCulate <Ch> :FSIMulator:BALun:TOPology:BALanced[:PPORts]?
Description
Sets or reads out the ports assigned to the balanced device when
its type is "BALance".
(command/query)
Target
The channel <Ch>={[1]|2|...16}
Parameters
<port1> First port number
<port2> Second port number
Query Response
<port1>, <port2>
Preset Value
1,2
Related Commands
CALC:FSIM:BAL:DEV
Equivalent Softkeys
Analysis > Fixture Simulator > Topology > Port 1 (bal)
