Copper Mountain Technologies S2 Series User Manual

S2VNA and S4VNA SCPI Programming Manual
41
CALC:FSIM:BAL:CZC:BPOR:Z0
CALCulate< Ch >:FSIMulator:BALun:CZConversion:BPORt< Bpt >:Z0[:R] <numeric>
CALCulate< Ch >:FSIMulator:BALun:CZConversion:BPORt< Bpt >:Z0[:R]?
Description
Sets or reads out the impedance value for the common impedance
conversion function of the balanced port. The impedance is real.
The default impedance value equals to 25 Ω.
(command/query)
Target
Balanced Port <Bpt> of channel <Ch>,
<Ch>={[1]|2|...16}
<Bpt>={[1]|2}, 1 or 2 for the Bal-Bal topology, always 1 for the SE-Bal,
SE-SE-Bal and Bal topology.
Parameter
<numeric> the new value of the common impedance of the balanced
port from 1 mΩ to 10 MΩ.
Unit
Ω (Ohm)
Out of Range
Sets the value of the limit, which is closer to the specified value.
Query Response
<numeric>
Preset Value
25 Ω
Equivalent Softkeys
Analysis > Fixture Simulator > Cmn ZConversion > Bal Port n
