Copper Mountain Technologies S2 Series User Manual

S2VNA and S4VNA SCPI Programming Manual
147
CALC:RLIM:REP?
CALCulate <Ch> [:SELected]:RLIMit:REPort[:DATA]?
Description
Reads out the data array, which is the ripple limit test result.
The array size is 1+3N, where N is the number of ripple limit bands.
For the n–th point, where n from 1 to N:
<numeric 1> N total number of the bands
<numeric 3n–1> n number of the band
<numeric 3n–0> Ripple value in the n–th band
<numeric 3n+1> Ripple limit test result in the n–th band:
0- Pass
1- Fail
(query only)
Target
The active trace of channel <Ch>,
<Ch>={[1]|2|...16}
Query Response
<numeric 1>, <numeric 2>, …<numeric 3N+1>
Equivalent Softkeys
None
