S2VNA and S4VNA SCPI Programming Manual
43
CALC:FSIM:BAL:DEV
CALCulate <Ch> :FSIMulator:BALun:DEVice <char>
CALCulate <Ch> :FSIMulator:BALun:DEVice?
Description
Selects the type of balanced device of the balance-unbalance
fixture simulation function
(command/query, S4 only).
Target
The channel <Ch>={[1]|2|...16}
Parameter
<char> Specifies type of the balanced device:
SBALanced : Unbalance-Balance (3 ports)
BBALanced : Balance-Balance (4 ports)
SSBalanced : Unbalance-Unbalance-Balance (4 ports)
BALanced : Balance (2 ports)
Query Response
{SBAL|BBAL|SSB|BAL}
Preset Value
BBAL
Equivalent Softkeys
Analysis > Fixture Simulator > Topology > Device > {SE-Bal | Bal-Bal | SE-
SE-Bal | Bal }
