Copper Mountain Technologies S2 Series User Manual

S2VNA and S4VNA SCPI Programming Manual
178
DISP:WIND:TRAC:Y:PDIV
DISPlay:WINDow <Ch> :TRACe <Tr> :Y[:SCALe]:PDIVision <numeric>
DISPlay:WINDow <Ch> :TRACe <Tr> :Y[:SCALe]:PDIVision?
Description
Sets or reads out the trace scale. Sets the scale per division, when
the data format is the rectangular format. Sets the full scale value,
when the data format is the Smith chart format or the polar format.
Target
Trace <Tr> of channel <Ch>,
<Tr>={[1]|2|...16}
<Ch>={[1]|2|...16}
Parameter
<numeric> the scale value from 10E–18 to 1E18
Out of Range
Sets the value of the limit, which is closer to the specified value.
Unit
{ dB |° |s }
Query Response
<numeric>
Preset Value
Varies depending on the format.
Logarithmic Magnitude: 10 dB/Div
Phase: 40 °/Div
Expand Phase: 100 °/Div
Group Delay: 10e–9 s/Div
Smith Chart, Polar, SWR: 1 /Div
Linear Magnitude: 0.1 /Div
Real part, Imaginary part: 0.2 /Div
Equivalent Softkeys
Scale > Scale
