CALC:FSIM:BAL:TOP:PROP:STAT
CALCulate <Ch> :FSIMulator:BALun:TOPology:PROPerty:STATe {OFF|ON|0|1}
CALCulate <Ch> :FSIMulator:BALun:TOPology:PROPerty:STATe?
Description
Turns ON/OFF the BalUn property indication on the screen.
(command/query)
Target
The channel <Ch>={[1]|2|...16}
Parameter
{ON|1} : ON
{OFF|0} : OFF
Query Response
{0|1}
Preset Value
0
Equivalent Softkeys
Analysis > Fixture Simulator > Topology > Property
CALC:FSIM:EMB:NETW:FIL
CALCulate <Ch> :FSIMulator:EMBed:NETWork <Nk> :FILename <string>
CALCulate <Ch> :FSIMulator:EMBed:NETWork <Nk> :FILename?
Description
Sets or reads out the name of 4-port touchstone file (*.s4p) of the
4-port network embedding/de-embedding feature.
The file contains the circuit S–parameters in Touchstone format.
(command/query)
Target
The channel <Ch>={[1]|2|...16},
The Network <Nk>={[1]|2}
Parameter
<srting>, up to 256 characters
Notes
If the full path of the file is not specified, the \FixtireSim subdirectory of
the application directory will be searched for the file.
Equivalent Softkeys
Analysis > Fixture Simulator > De–Embedding S4P > File (ntwk1), File
(ntwk2)
