Configure System Information
103
M4300 Series and M4300-96X Fully Managed Switches User Manual
6. Use Maximum Hop Count to enter the maximum number of hops a client request can take
before being discarded.
The range is (1 to 16). The default value is 4.
7. Select the Admin mode Disable or Enable radio button.
When you select Enable, DHCP requests are forwarded to the IP address you entered in
the Server Address field.
8. Use Minimum W
ait T
ime to enter a Minimum Wait Time in seconds.
This value is compared to the time stamp in the client's request packets, which
represents the time since the client was powered up. Packets are forwarded only when
the time stamp exceeds the minimum wait time. The range is (0 to 100).
9. Select the
Circuit ID Option mode Disable or Enable radio button.
If you select Enable, Relay Agent options are added to requests before they are
forwarded to the server and removed from replies before they are forwarded to clients.
10. Click the Apply
button.
Your settings are saved.
The following table describes the DHCP Relay Statistics fields.
DHCP L2 Relay
Configure Global DHCP L2 Relay Settings
To configure global DHCP L2 Relay settings:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
Table 38. DHCP Relay Status
Field Description
Requests Received The total number of DHCP requests received from all clients since the
last time the switch was reset.
Requests Relayed The total number of DHCP requests forwarded to the server since the
last time the switch was reset.
Packets Discarded The total number of DHCP packets discarded by this Relay Agent since
the last time the switch was reset.
