Configure Switching Information
243
M4300 Series and M4300-96X Fully Managed Switches User Manual
The following table describes the nonconfigurable information displayed on the page.
Configure MLD Snooping
You can configure the parameters for MLD snooping, which is used to build forwarding lists
for multicast traffic. Only a user with read/write access privileges can change the data on this
page.
To configure MLD snooping:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Switching> Multicast > MLD Snooping > Configuration.
Table 87. Querier VLAN Configuration
Field Description
Operational State The operational state of the IGMP snooping querier on a VLAN. It can
be in any of the following states:
Querier:
The snooping switch is the querier in the VLAN.
The
snooping switch sends out periodic queries with a time interval
equal to the configured querier query interval. If the snooping
switch finds a better querier in the VLAN, it moves to non-querier
mode.
Non-Querier: The snooping switch is innNon-querier mode in the
VLAN. If the querier expiry interval timer expires, the snooping
switch moves into querier mode.
Disabled:
The snooping querier is not operational on the VLAN.
The snooping querier moves to disabled mode when IGMP
snooping is not operational on the VLAN or when the querier
address is not configured or the network management address is
also not configured.
Operational V
ersion The operational IGMP protocol version of the querier.
Last Querier Address The IP address of the last querier from which a query was snooped on
the VLAN.
Last Querier Version The IGMP protocol version of the last querier from which a query was
snooped on the VLAN.
Operational Max Response Time Displays maximum response time to be used in the queries that are
sent by the snooping querier
.
