Configure System Information
144
M4300 Series and M4300-96X Fully Managed Switches User Manual
The following table describes the LLDP-MED Local Device Information fields.L
View LLDP-MED Remote Device Information
To view LLDP-MED remote device information:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
Table 49. LDP-MED Local Device Information
Field Description
Network Policy Information: Specifies if network policy TLV is present in the LLDP frames.
Media Application Type The application type. Types of application types are unknown,
voicesignaling, guestvoice, guestvoicesignalling, softphonevoice,
videoconferencing, streammingvideo, vidoesignalling.
Each application type that is received has the VLAN ID, priority, DSCP,
tagged bit status and unknown bit status.
A port can receive one or
many such application types.
If a network policy
TLV was transmitted, only then would this
information be displayed
Inventory: Specifies if inventory TLV is present in LLDP frames
Hardware Revision Specifies hardware version.
Firmware Revision Specifies Firmware version.
Software Revision Specifies Software version.
Serial Number Specifies serial number.
Manufacturer Name Specifies manufacturers name.
Model Name Specifies model name.
Asset ID Specifies asset ID.
Location Information: Specifies if location TLV is present in LLDP frames.
Sub Type Specifies type of location information.
Location Information The location information as a string for given type of location ID.
