Multicast Routing
422
M4300 Series and M4300-96X Fully Managed Switches User Manual
View the IGMP Membership
To view the IGMP membership:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Routing> Multicast > IGMP > IGMP Membership.
6. Use the Search menu to search for multicast entries by interface or group IP address.
• Select Interface from the menu, enter the interface in unit/slot/port format (for
example, 1/0/13), and click the Go button.
If the entry exists, the entry is displayed as the first entry, followed by the remaining
entries.
• Select Group IP from the menu, enter the multicast group IP
, and c
lick the Go button.
If the entry exists, that entry with the matching group IP address is displayed as the
first entry, followed by the remaining entries.
An exact match is required.
7. To refresh the page with the latest information on the switch, click the Update button.
The following table describes the nonconfigurable information that is displayed.
Table 159. Multicast IGMP Membership
Field Description
Interface The interface on which multicast packets are forwarded.
Group IP The IP multicast group address for which data is to be displayed.
Compatibility Mode This parameter shows group compatibility mode (v1, v2, and v3) for this
group on the specified interface.
