NETGEAR M4300 User Manual

Configure Switching Information
282
M4300 Series and M4300-96X Fully Managed Switches User Manual
Configure the Loop Protection Settings for Ports and View the
Loop Protection State
Before you can configure loop protection for individual ports, you must globally enable loop
protection (see Configure the Global Loop Protection Settings on page 280).
 To enable and configure loop protection for a port and view the loop protection state
on the switch:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Switching> L2 Loop Protection > L2 Loop Protection Configuration.
6. Select one of the following options to specify which ports are displayed on the page:
• Click LAG to show the list of all LAG interfaces.
• Click All to show the list of all physical ports as well as LAG interfaces.
7. Use one of the following methods to select a port:
• In the Go T
o Port field, enter the port in the unit/slot/port format and click on the
Go
button.
• Next to the Port column, select the check box for the port that you want to configure.
