Manage Device Security
551
M4300 Series and M4300-96X Fully Managed Switches User Manual
Configure Private VLAN Association Settings
To configure private VLAN association:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Security > T
raffic Control > Private VLAN > Private VLAN
Association
Configuration.
6. Use Primary VLAN to select the primary VLAN ID of the domain.
This is used to associate secondary VLANs with the domain.
7. Use Secondary VLAN(s) to display all the statically created VLANs (excluding the primary
and default VLANs).
This control is used to associate VLANs with the selected primary VLAN.
8. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable information displayed on the page.
Table 201. Private VLAN Association
Field Description
Isolated VLAN The isolated VLAN associated with the selected primary VLAN.
Community VLAN(s) The list of community VLANs associated with the selected primary
VLAN.
