Multicast Routing
449
M4300 Series and M4300-96X Fully Managed Switches User Manual
The following table describes the nonconfigurable information that is displayed.
View the IPv6 MLD Groups
To view the IPv6 MLD groups:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Routing> IPv6 Multicast > MLD > MLD Groups.
6. Use the Search menu to search for multicast entries by interface or group:
• Select Interface from menu, enter the interface in unit/slot/port format (for example
1/0/13), and click the Go button.
Table 173. IPv6 MLD Routing Interface Statistics
Field Description
Interface The interface for which data is to be displayed.
Querier Status Indicates whether the selected interface is an MLD querier or non-querier
on the subnet it is associated with.
Querier IP The address of the MLD querier on the IP subnet to which the selected
interface is attached.
Querier Up Time The time in seconds since the MLD interface querier was last changed.
Querier Expiry Time The time in seconds remaining before the other querier present timer
expires. If the local system is the querier
, this is zero.
W
rong Version Queries Received The number of queries received whose MLD version does not match the
MLD version of the interface.
Number of Joins Received The number of times a group membership was added on the selected
interface.
Number of Groups The current number of membership entries for the selected interface in the
cache table.
