Page #334 background image
Routing
334
M4300 Series and M4300-96X Fully Managed Switches User Manual
Encrypt. If you select Encrypt, you are prompted to enter both an authentication key
and an authentication ID. Encryption uses the MD5 Message-Digest algorithm. All
routers on the network must be configured with the same key and ID.
11. Enter the RIP Authentication Key for the specified interface.
If you selected Authentication Type None, you are not prompted to enter a key
. If you
selected Simple or Encrypt, the key can be up to 16 octets long. The key value is
displayed only if you are logged on with read/write privileges.
12. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable information that is displayed.
Route Redistribution
Use this page to configure the RIP route redistribution parameters. The allowable values for
each field are displayed next to the field. If any invalid values are entered, an alert message
is displayed with the list of all the valid values.
To configure advanced RIP route redistribution settings:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Routing > RIP >
Advanced > Route Redistribution
.
Table 120. RIP Advanced Interface Configuration
Field Description
Bad Packets Received The number of RIP response packets received by the RIP process that
were subsequently discarded for any reason.
Bad Routes Received The number of routes in valid RIP packets that were ignored for any
reason (for example, unknown address family
, or invalid metric).
Updates Sent The number of triggered RIP updates actually sent on this interface.
This explicitly does
not include full updates sent containing new
information.
IP Address The IP address of the router interface.
Link State Indicates whether the RIP interface is up or down.
