NETGEAR M4300 User Manual

Routing
324
M4300 Series and M4300-96X Fully Managed Switches User Manual
The default is No.
9. Use IP Address to define the IP address of the VLAN interface.
10. Use Network Mask to define the subnet mask of the VLAN interface.
11. Click the Apply button.
Your settings are saved.
Configure VLAN Routing
 To configure VLAN routing:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login window opens.
3. Enter the user name and password.
The default admin user name is
admin and the default admin password is blank, that is,
do not enter a password.
4. Click the Login button.
The System Information page displays.
5. Select Routing> VLAN > VLAN Routing.
6. Select the VLAN ID.
This field displays the IDs of all the VLANs configured on this switch.
7. Use IP Address to enter the IP address to be configured for the VLAN routing interface.
8. Use Subnet Mask to enter the subnet mask to be configured for the VLAN routing interface.
9. Click the Add button.
The VLAN routing interface is added for the selected VLAN ID.
The following table describes the nonconfigurable information displayed on the page.
Table 116. VLAN Routing Configuration
Field Description
Port The interface assigned to the VLAN for routing.
MAC Address The MAC Address assigned to the VLAN routing interface
